One end housing insertion another side welded microphone with twisted wire
Cut Strip Terminate& Solder
54
Model：One end housing insertion another side welded microphone with twisted wire
Stripping/ Twisting length:
Front end stripping 0-5mm,
rear end stripping 0-5mm
Cutting length: 15-500mm
Wire OD: 0.5-1.0
Rubber shell type: 1.0,1.25
Microphone head type: 40,60
Front end stripping 0-5mm,
rear end stripping 0-5mm
Cutting length: 15-500mm
Wire OD: 0.5-1.0
Rubber shell type: 1.0,1.25
Microphone head type: 40,60
Technical Data
|
EW-9275 |
|
|
Applicable wire range |
AWG28-AWG18 |
|
Stripping/ Twisting length |
Front end stripping 0-5mm, rear end stripping 0-5mm |
|
Cutting length |
15-500mm(Length can be customized) |
|
Capacity |
1800pcs/hour(Capacity will vary according to length.The machine can work continuously for 24 hours) |
|
Wire OD |
0.5-1.0 |
|
Rubber shell type |
1.0,1.25 |
|
Microphone head type |
40,60 |
|
Detection |
Terminal pressure detection, Core wire, terminal, Rubber shell, Microphone direction,Welding visual inspection |
|
Power |
220V/110V/50/60HZ |
|
Processing digits |
Five groups, can be twisted together |
|
Machine Dimension |
2133*1742*1700mm |
|
Machine Weight |
700Kgs |
|
Air pressure |
0.5-0.7MPA |
Feature
● Using high-quality components, the machine runs smoothly, quickly, with low noise, high stability and reliability, and can operate continuously for a long time.
● Function integration: This device integrates multiple functions such as single end crimping, tinning, shell insertion, and microphone soldering for electronic wires.
● Fully automated operation: The cutting stripping crimping of terminals, insertion of housing , welding of microphone heads, the entire process is fully automated.
● Equipped with advanced control systems and sensors, it can achieve functions such as automatic feeding, positioning, processing, and detection.
Application Range
