Model |
EW-9245 |
|
Cutting Length Range |
25mm-240mm |
|
Terminal Compatibility |
Supports IPEX, Speedtech, Consort, Kosenic, Caimei series terminals |
|
Cable Compatibility |
0.81-1.37mm diameter range |
|
Robotic Arm |
4-axis arm (Toshiba/Epson Japan) |
|
Production Process |
Dual-head termination |
|
Yield Rate |
¡Ư99% (Tested with Shenyu cables & genuine IPEX terminals) |
|
Equipment Utilization |
¡Ư95% |
|
Processing Precision |
Stripping tolerance: ¡À0.1mm; Length tolerance: ¡À0.2mm |
|
Production Efficiency |
850-1050 PCS/H (Varies with stripping length) |
|
Testing System |
HV/Short-circuit/Conductivity test + Vision positioning |
|
Operation Mode |
Dual-Robot Synchronized Work |
|
Control Interface |
Touchscreen + PC |
|
Total Power |
Approx. 3.5KW |
|
Weight |
Approx. 1400kg |
|
Operating Voltage |
AC220V¡À10V |
|
Air Pressure |
Air Pressure |
|
Dimensions |
2300(L)¡Á1600(W)¡Á2200(H) mm |
