EW-05H+P |
||
|
Processing range |
2.5 - 120 mm² |
|
|
Cutting length |
1 - 99999.9 mm |
|
|
Cutting length tolerance |
< 0.002 * L (L = cutting length) |
|
|
Maximum guide tube diameter |
27 mm |
|
|
Stripping length (side I) |
Cable jacket - Full strip: 1 - 300 mm - Half strip: 1 - 1000 mm |
|
|
Stripping length (side II) |
Cable jacket - Full strip: 1 - 150 mm - Half strip: 1 - 500 mm |
|
|
Productivity |
2000 pcs./h(Depending on the length of the line) |
|
|
Compressed air connection |
0.5 - 0.8 MPa |
|
|
Blade material |
Imported high speed steel |
|
|
Display mode |
7-inch touch screen |
|
|
Driving mode |
24-wheel driving |
|
|
Feeding mode |
By belts |
|
|
Power supply |
110, 220 V (50 - 60 Hz) |
|
|
Weight |
275kg |
|
|
Dimension |
1020 * 590 * 1140 mm |
|
