Model

EW-8990

Applicable wire range

0.3-6mm2 (AWG9-AWG23)

Cutting length

60-99999mm

Stripping length

0.1-18mm

Cut precision

±1 (1+0.002*L) mm, L=cut length

Crimping force

3.0T

Crimping Stroke

30mm or 40mm stroke both available

Feeding speed

Max. 8.0m/s

Productivity

4500~ 5000 pcs/hour

Air pressure

0.5-0.7Mpa

Stripping/Cutting accuracy

700mm*800mm*1500mm (length, width and height)

Optional

348KG

Power supply

220V/110V(50HZ/60HZ)

Weight

1100Kg

Dimension

3500*1200*1700mm

Power

1800W
